KYY-109Y
KYY
Availability: | |
---|---|
Quantity: | |
1. Touch screen man-machine interface with simple operation.
2. The machine running is monitored.It is very convenient to fault resolution because faults will be showed on the touch screen automatic.
3. Film sealing dies(up and down) is separate type. When sealing film,press the tape and tape cord separately to assure strength of welding and without damage the tape,make zipper durable by water wash.
4. The film appearance beautiful,high strength and no hurt to tape.
5. Mechanical hand holds film which can set length of film as required, no missing and deflected film.
6. Film sealing near to teeth for strength fixing of pin and box.
7. Additional radiating device makes horn temperature steady.No adhere film to horn, no film becomes white.
8. Separate film cutter to longer mold life.
9. The safety protection alarm system can avoid mechanical injuries.
10. The horn temperature is monitored and adjusted automatically.
11. The machine can seal groove film to improve the strength,beauty the appearance and satisfy using of zipper.
Model: | KYY-109Y |
Average output: | 900PCS/H |
Power: | 2.0KW |
Volt: | 220V |
Frequency: | 50/60HZ |
Net weight | 280kgs |
Gross weight: | 300kgs |
Machine dimension (L*W*H): | 90*70*185cm |
Packing measurements(L*W*H): | 200*80*210cm |
Product Detail
1. Touch screen man-machine interface with simple operation.
2. The machine running is monitored.It is very convenient to fault resolution because faults will be showed on the touch screen automatic.
3. Film sealing dies(up and down) is separate type. When sealing film,press the tape and tape cord separately to assure strength of welding and without damage the tape,make zipper durable by water wash.
4. The film appearance beautiful,high strength and no hurt to tape.
5. Mechanical hand holds film which can set length of film as required, no missing and deflected film.
6. Film sealing near to teeth for strength fixing of pin and box.
7. Additional radiating device makes horn temperature steady.No adhere film to horn, no film becomes white.
8. Separate film cutter to longer mold life.
9. The safety protection alarm system can avoid mechanical injuries.
10. The horn temperature is monitored and adjusted automatically.
11. The machine can seal groove film to improve the strength,beauty the appearance and satisfy using of zipper.
Model: | KYY-109Y |
Average output: | 900PCS/H |
Power: | 2.0KW |
Volt: | 220V |
Frequency: | 50/60HZ |
Net weight | 280kgs |
Gross weight: | 300kgs |
Machine dimension (L*W*H): | 90*70*185cm |
Packing measurements(L*W*H): | 200*80*210cm |
Product Detail
